ATWY8-300-2-B Dual-Mast Aluminum Alloy Lifting Platform: 8m Mid-High Altitude Heavy-Duty Workhorse

8m Height: The "Sweet Spot" for Mid-High Altitude Heavy-Duty Tasks

As a dual-mast lifting platform built for heavy loads, ATWY8-300-2-B hits the perfect balance between reach and flexibility with its 8m working height. It outperforms 6m platforms by accessing 8m-high areas—like factory ventilation ducts, warehouse top-level shelves, and stadium lighting trusses—while remaining more maneuverable than 10m models, making it ideal for spaces where "just enough height without extra bulk" matters.

The 1.2×0.63m platform isn’t just spacious enough for 2 workers + 300kg of tools (e.g., a 25kg angle grinder, 40kg pipe fittings, and a 30m cable reel) but also features 5mm anti-slip ridges along the edges. This ensures tools stay in place during lifts, even when carrying heavy metal materials—critical for 8m-high precision tasks like pipe alignment or equipment installation.

Dual-Mast Strength: 300kg Load at 8m, Stable as a Rock

Crafted from high-strength aluminum alloy (6061-T6, tensile strength ≥280MPa), the dual-mast frame of ATWY8-300-2-B uses a symmetrical load-bearing design. Each mast is 5mm thick at key stress points, with reinforced connectors that cut deflection to ≤2mm when lifting 300kg at 8m—20% more stable than single-mast platforms of the same height.

This stability shines in scenarios like 8m-high steel structure maintenance: even with 2 workers leaning slightly to adjust bolts, the platform stays steady, eliminating the "sway" that risks tool drops or misalignment.

550kg Weight: Heavy-Duty Power Without the Bulk

At 550kg, ATWY8-300-2-B is engineered to be "strong but movable." Its 1.55×0.85×2.0m footprint fits through 1m-wide workshop doors or freight elevators, while the ergonomic push handle lets one person tow it across concrete floors with ≤65N of force (about the effort to pull a large suitcase).

The secret? A "smart thickness" design: load-bearing parts stay thick (5mm) for strength, while non-critical areas slim down to 3mm—keeping weight in check without sacrificing 8m-height durability.

1.5kW Efficiency: Fast, Steady Lifts for 8m Tasks

The 1.5kW motor of ATWY8-300-2-B is tuned for 8m heights and 300kg loads, lifting at 0.35m/s—so it reaches 8m in just 23 seconds, 15% faster than standard 8m heavy-duty lifts. Its hydraulic system ensures both masts rise in sync (error ≤1mm), preventing uneven tilting that could shift heavy tools.

Run ATWY8-300-2-B for 5 hours straight (lifting every 12 minutes with 300kg) and the motor stays cool—temperature rise ≤45℃—making it reliable for all-day warehouse restocking or factory maintenance. It works with 220V mains (110V optional), handling ±10% voltage swings without glitches.

Smooth Mobility: Quiet, Floor-Friendly Even Under Load

Fitted with 90mm-wide polyurethane tires (3mm deep treads), ATWY8-300-2-B glides over floors with minimal noise (≤60dB)—no clanging in hospitals or shopping malls. The tires, reinforced with steel belts, barely deform (≤5mm) under 300kg, so they won’t scuff epoxy floors or leave marks on warehouse concrete.

With a 1.8m turning radius, ATWY8-300-2-B navigates tight spots like 1.2m-wide warehouse aisles or between factory equipment, making it easy to reposition for 8m-high tasks in crowded spaces.

Safety First: Dual Layers of Protection for 8m Heights

Anti-Tilt Security: A dual-axis level (15Hz sampling) locks ATWY8-300-2-B if it tilts over 3°, while 1.8×1.5m hidden outriggers spread the 300kg load to ≤0.3MPa ground pressure—no sinking on wooden or tiled floors.

Emergency Control: The emergency descent valve of ATWY8-300-2-B, upgraded for 8m heights, lets you adjust lowering speed (0.2-0.3m/s) if power cuts out. Pair it with the manual pump, and you’re on the ground in 40 seconds—no stranded workers.

Tool Security: Four 10mm bolt holes on the platform let you strap down heavy gear (like 100kg generators), so nothing shifts mid-lift.

Custom Upgrades: Tailored to Your 8m Tasks

Battery-Powered Version (12V/120Ah): Runs 6 hours on a charge, perfect for outdoor 8m jobs—like installing streetlights or inspecting billboards—with no need for cords.

Explosion-Proof Model (Ex dⅡBT4): Anti-static coating and spark-free components make ATWY8-300-2-B safe for 8m-high pipe checks in chemical plants, where flammable gases are a risk.

Powered Drive Option: Adds electric wheels (2km/h) to cut repositioning time by 70% in large warehouses—no more straining to move ATWY8-300-2-B between 8m shelves.

Where It Shines: 8m Heavy-Duty Scenarios

Warehouse Top-Shelf Restocking: ATWY8-300-2-B hauls 300kg of boxes to 8m shelves in one trip, cutting trips by half compared to smaller lifts.

Factory Equipment Installation: Carries 2 workers + 200kg machinery to 8m-high production lines, with dual-mast stability for precise alignment.

Stadium Maintenance: Lifts 2 technicians + 150kg lighting gear to 8m trusses, with quiet tires that won’t disturb events.

Municipal Pipe Repair: Reaches 8m-high water pipes in narrow alleyways, with the battery version working where there’s no power.

ATWY8-300-2-B redefines 8m heavy-duty lifting: it’s tall enough for mid-high tasks, stable enough for 300kg loads, and nimble enough for tight spaces. Whether you’re moving cargo, fixing equipment, or installing fixtures, it turns 8m-high heavy work into a smooth, efficient job.
