Short Description:

Extended Platform for Expanding Work Range: It effectively expands the working area, allowing operators to reach further positions easily without frequent equipment movement....

• Model: BJPT1012LD-C
• Max. Working height: 12m
• Max. Platform height: 10m
• Machine length: 2.528m
• Machine width: 1.39m
• Machine height (the guardrail is not folded): 2.571m
• Machine height (the guardrail is folded): 2.041m
• Working platform size: 2.271×1.11m
• Platform extension size: 0.9m
• Rated load: 320kg
• Extended platform safe working load: 113kg
• Liftingmotor: 48V/4.5KW
• Machine travel speed (folded state): 1.8Km/h
• Lift speed: 84/38sec
• Max. Gradeability: 30%
• Working maximum allowable angle: 1.5° - 3°
• Storage battery: 8×12V/100Ah
• Charger: 48V/35A
• Machine weight: 3200kg
