Short Description:

Reliable Safety Guarantee: The maximum allowable working angle data reflects its safety performance, providing reliable safety protection for operators....

• Model: BJSP1214TL-A
• Rated load: 320 kg
• Total Weight: 3910 kg
• Rated load of extension platform: 120 kg
• Maximum number of workers: 2
• Working height (A + 2): 13.8 m
• Maximum platform height: 11.8 m
• Length of the whole machine (B): 2.67 m
• Overall width (C): 1.60 m
• Overall width - fence folding (D): 2.14 m
• Platform extension size: 0.9 m
• Machine travel distance (stowed / drifted): 0 - 1.8 km/h
• Rising / falling speed (s): 70/68 sec
• Maximum climbing ability: 30%
• Maximum allowable working angle: 1.5° / 3°
• Power source: 24V DC (8*6V225Ah Battery)
