Short Description:

High - efficiency and Low - noise Operation Experience: Using advanced motors and transmission systems, the noise during operation is controlled at a low level....

• Model: BJSP1212-A
• Rated load: 320 kg
• Total Weight: 3030 kg
• Rated load of extension platform: 120 kg
• Maximum number of workers: 2/-
• Working height (A + 2): 13.8 m
• Maximum platform height: 11.8 m
• Length of the whole machine (B): 2.45 m
• Overall width (C): 1.18 m
• Overall width - fence folding (D): 2.04 m
• Platform extension size: 0.9 m
• Machine travel distance (stowed / drifted): 3.2 / 0.8 km/h
• Rising / falling speed (s): 70/68 sec
• Maximum climbing ability: 25%
• Maximum allowable working angle: 1.5° / 3°
• Power source: 24V DC (4*12V150Ah Battery)
