Short Description:

Precise and Stable Platform Leveling: Equipped with an advanced automatic leveling system, it improves operation accuracy and safety....

• Model: BJJZ06A-C
• Max. Working height: 8m
• Max. Platform height: 6m
• Working platform size(L × W × H): 2.26×0.81×1.1m
• Overall size (L × W × H, the guardrail is not folded): 2.48×0.84×2.2m
• Overall size (L × W × H, guardrail folded): 2.48×0.84×1.73m
• Platform extension size: 0.9m
• Min. ground clearance: 0.1/0.02m
• Wheelbase: 1.89m
• Rated load: 380kg
• Extended platform safe working load: 113kg
• Turning radius (inner wheel/outer wheel): 0/3.1m
• Driving motor: -
• Lifting motor: -
• Lifting speed: 3 - 5m/min
• Machine travel speed (folded state): 3.5km/h
• Machine travel speed (lifting state): 0.8km/h
• Max. Gradeability: 25%
• Working maximum allowable angle: 1.5°/3°
• Drive wheel: ⌀381×127mm
• Front wheel: ⌀381×127mm
• Storage battery: 4 x 12V /103Ah, (Optional lithium - battery 24V/230Ah)
• Machine weight: 1880kg
