Short Description:

Convenient Transportation and Storage: With a reasonable volume design, it is convenient for transportation and storage....

• Model: BJ0508DEM-C
• Max. Working height: 6.5m
• Max. Platform height: 4.5m
• Working platform size(L × W × H): 1.29×0.7×1.05m
• Overall size (L × W × H, the guardrail is not folded): 1.39×0.81×2.09m
• Overall size (L × W × H, guardrail folded): 1.39×0.81×1.73m
• Platform extension size: 0.6m
• Min. ground clearance: 0.085/0.02m
• Wheelbase: 1.11m
• Rated load: 230kg
• Extended platform safe working load: 100kg
• Turning radius (inner wheel/outer wheel): 1.35m/0.3m
• Driving motor: -
• Lifting motor: -
• Lifting speed: 4 - 6m/min
• Machine travel speed (folded state): 3.5km/h
• Machine travel speed (lifting state): 0.5km/h
• Max. Gradeability: 25%
• Working maximum allowable angle: 1.5°/3°
• Drive wheel: ⌀255×80mm
• Front wheel: ⌀255×80mm
• Storage battery: 2×12V/103Ah
• Machine weight: 1010kg
