Short Description:

Safe Sleeve-Type Mast Lift Platform: Equipped with automatic braking, emergency descent, and tilt alarm safety protections to ensure safe and efficient high-altitude operations....

• Model: ATFB11.2-B
• Max. Working Height: 11.5 m
• Max. Platform Height: 9.5 m
• Max. Working Horizontal Extension: 3.48 m
• Crossing Height: 7.89 m
• Travel Height: Full Height
• Platform Load Capacity: 200 kg
• Permitted Number of Users (Indoor/Outdoor): 2/1
• Stowed Heighta: 1.99 m
• Overall Dimensions (Length × Width): 2.85 m×1.00 m
• Platform Dimensions (Length × Width): 0.90 m×0.75 m
• Permitted Tilt Angle (Front/Back / Left/Right): 2°/2°
• Turret Rotation Angle: 345°
• Rotation Type: Discontinuous
• Turntable Tail Swing: 0.07 m
• Fly - Arm Vertical Rotation: 130°(+70/-60)
• Fly - Arm Length: 1.66 m
• Turning Radius (Inside/Outside): 0.1 m/1.68 m
• Travel Speed (Raised/Stowed): 0.5 km/h/4.5 km/h
• Lifting/Lowering Speed: 55/40 s
• Ground Clearance (Raised/Stowed): 0.02 m/0.1 m
• Gradeability: 25%
• Battery: 24 V 260 Ah
• Drive: AC
• Tyres: 406×127 mm
• Wheelbase: 1.2 m
• Overall Weight: 2950 kg
