3.6 M Proven Reliable Sleeve Type Mast Lift For Sale

Sleeve Vertical Lifting Platform

Short Description:

Get the Self-Propelled Vertical Mast with proportional control for precise operation. Auto pothole protection, full-stroke travel, and non-marking tires ensure safety and smooth movement. Auto-braking, emergency features, and fault diagnosis boost efficiency in high-altitude tasks....


  • MODEL: ATWP3.6-6100-C
  • Max. Working Height: 5.6 m
  • Max. Platform Height: 3.6 m
  • Loading Capacity: 227 kg
  • Ext. Platform Capacity: 114 kg
  • Overall Length: 1.36 m
  • Overall Width: 0.76 m
  • Overall Height: 1.7 m
  • Platform Dimension: 1.28 m×0.70 m
  • Ext. Platform Length: 0.51 m
  • Wheel Base: 1.04 m
  • Inner Turning Radius: 0.3 m
  • Outer Turning Radius: 1.4 m
  • Travel Speed(Stowed): 4 km/h
  • Travel Speed(Raised): 1.1 km/h
  • Up/Down Speed: 31/32 sec
  • Gradeability: 25%
  • Drive Tyres: Φ305×100 mm
  • Drive Motors: 2×24 V DC/0.5 kW
  • Lifting Motor: 24 V DC/1.2 kW
  • Battery: 2×12 V/100 Ah
  • Charger: 24 V/15 A
  • Weight: 810 kg

Product Detail

Product Description

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

Sleeve Vertical Lifting Platform

The professional Self-Propelled Vertical Mast delivers flexible, precise operation via its proportional control system, adapting seamlessly to diverse high-altitude tasks. Its automatic pothole protection system proactively mitigates risks by detecting and avoiding hazards in real time, ensuring safe navigation across uneven terrain. Full-stroke mobility paired with non-marking tires ensures unrestricted movement across all surfaces—indoors or out—without surface damage, maximizing operational versatility.

Safety and reliability are prioritized with integrated features like automatic braking, emergency descent/stop capabilities, explosion-proof hydraulic tubing, and a smart fault diagnosis system that identifies issues quickly. Together, these elements create a secure, stable, and high-performance solution, elevating productivity while safeguarding operators and worksites. Ideal for demanding industrial environments, this mast combines efficiency, durability, and advanced safety to redefine high-altitude operations.
